Antenna Options

Virtual Access offers a variety of antennas as every 3G/4G wireless deployment is different. When selecting an antenna for your device, you should consider factors such as the installation environment, mounting options and the distance between router and antenna location. We provide most antennas with a cable length of up to 5 meters. We recommend you keep the cable length as short as possible to minimise cable-caused attenuation.

3G SMA Male Hinged Antenna
3G-SMA-Male-Hinged-Antenna

Designed primarily for use with 3G and 4G cellular Gateways and routers.
The antenna has an SMA Male connector. It can be used straight or hinged 90 degrees.
The antenna has a wide-band high efficiency response on nearly all 2G/3G/4G frequency bands worldwide, and can also be used for other cellular and wireless applications such as GSM, and 2.4GHz WI-FI.

Product Description

  • Part number: 160-00002
  • Dimensions: 157 x 21mm
  • Mounting method: Direct contact
  • Connector: SMA/FME/TNC
  • Frequency: 850/900/1800/1900/2100MHz
  • VSWR ≤ 2
  • Gain: 2.5dBi
  • Max input power: 50W
  • Input impedance: 50Ω
  • Polarization: Vertical
  • Antenna length: 140mm
  • Storage temperature: -30oC to 70oC
  • Operating temperature: -30oC to 75oC

Wall Mount Flexible Whip Monopole
Wall Mount-flexible-antenna
HIGH GAIN 2G/3G/4G WIDE-BAND CELLULAR ANTENNA
High performance on all common 2G/3G/4G bands worldwide. Delivers wider coverage areas and more reliable connections for automotive and industrial applications.

Product Description

  • Part number: 160-00018
  • Dimensions: 248 x 5mm
  • Base diameter: 17.08 x 0.2mm
  • Whip diameter: 4 x 0.2mm
  • Mounting method: Direct contact
  • Connector: SMA Male
  • Frequency: 698-969/1710-2690MHz
  • Gain: 2.5dBi
  • Input power: 2W
  • Input impedance: 50Ω
  • Polarization: Linear
  • Temperature: -40oC to 85oC
  • Humidity: Non-condensing 65 to 95 RH

COMBINATION HIGH PERFORMANCE GPS CLONASS & 2G/3G/4G LTE ANTENNA Combination high performance GPS CLONASS 2G/3G/4G antenna
Optimus MA220
COMBINATION HIGH PERFORMANCE GPS CLONASS & 2G/3G/4G LTE ANTENNA
Simplifies automotive, Telematic and fleet management systems worldwide. Can be attached to glass or under dashboard for covert installation.

Product Description

  • Part number: 160-00019
  • Dimensions: 62.8 x 68 x 12mm
  • Mounting method:  Adhesive
  • Connector: SMA Male
  • Frequency:  GPS: 1575.42±3MHz
  • VSWR ≤ 1.92:1 Max
  • Gain: 31dBi
  • DC power input:  3.3V
  • Input impedance:  50Ω
  • Polarization: Linear
  • Storage temperature: -40oC to 90oC
  • Operation temperature: -40oC to 80oC
  • Humidity: Non-condensing 65oC 96% RH

160-00027-MA208.Stream
MA.208 Stream
GPS/LTE/GSM/UMTS  CELLULAR ANTENNA
Low profile, heavy duty fully IP67 waterproof external M2M antenna for Telematics, transportation and remote monitoring applications.

Product Description

  • Part number: 160-00027
  • Dimensions: 35 x 35 x 4mm
  • Mounting method: Adhesive
  • Connector: SMA Male
  • Frequency: 698-969/1710-2690MHz
  • VSWR ≤ 3.6MHz
  • Gain: 3.5dBi
  • Input power: 2W
  • Input impedance: 50Ω
  • Polarization: Linear
  • Storage temperature: -40oC to 85oC
  • Operating temperature: -40oC to 85oC

Olypian 2-in-1 LTE-GPS-GLONASS antenna
Olympian 2 in 1
LTE 2G/3G/4G and GPS/GLONASS ANTENNA
Compact, high performance, combination LTE and GPS/GLONASS screw mount antenna for external use on vehicle and outdoor assets worldwide.

Product Description

  • Part number: 160-00033
  • Dimensions: 48H x 50D mm
  • Mounting method: Heavy duty screw mount
  • Connector: SMA Male
  • Frequency: LTE/2G/3G4G: 698/960/1710-2170/2500-2800MHz; GPS: 1575.42MHz; GLONASS: 1602MHz
  • VSWR: LTE: <3; GPS-GLONASS: <1.5-2.0
  • Gain: LTE: varies depending on cable length. See datasheet. GPS-GLONASS: 2dBic
  • Input power: LTE: 5W; GPS-GLONASS: 2.2-5V DC
  • Input impedance: LTE: <50ohm; GPS-GLONASS: 50Ω
  • Polarization: LTE: Linear; GPS-GLONASS RHCP
  • Storage temperature: -40oC to 85oC
  • Operating temperature: -40oC to 85oC

Mini screw mount monopole antenna
Miniature Hinged Screw Mount Monopole
2.4GHz RIGHT ANGLE SCREW MOUNT ANTENNA
Compact, monopole SMA Male right angle mount antenna is ideal for 2.4GHz wireless applications such as Bluetooth and wireless LAN.

Product Description

  • Part number: 160-00037
  • Dimensions: 28.5 x 17.2mm
  • Mounting method: Screw mount
  • Connector: SMA Male
  • Frequency: 2400-2500MHz
  • Bandwidth: 100MHz
  • Gain: 1.8dBi
  • Input power: 1W max
  • Impedance:  50Ω
  • Polarization: Vertical
  • Storage temperature: -40oC to 85oC
  • Operating temperature: -40oC to 85oC

straight-mini-monopole antenna
Minature Straight Screw Mount Monopole
2.4GHz STRAIGHT SCREW MOUNT ANTENNA
Compact Monopole SMA Male screw mount antenna ideal for 2.4GHz wireless applications such as WiFi, Zigbee and Bluetooth. Durable in high temperature environments where the antenna is placed near an engine or heat-generating components.

Product Description

  • Part number: 160-00039
  • Dimensions: 30 x 7.8mm
  • Mounting method: Screw mount
  • Connector: SMA Male
  • Frequency: 2400-2500MHz
  • Bandwidth: 100MHz
  • Gain: LTE: 1.3dBi
  • Input power: 1W max
  • Input impedance: 50Ω
  • Polarization: Vertical
  • Storage temperature: -40oC to 85oC
  • Operating temperature: -40oC to 150oC

Wideband 4G LTE Ibar Antenna
Wideband 4G LTE Ibar Antenna
LTE/GSM/ CDMA/DCS/PCS/WCDMA/UMTS/HSDPA/GPRS/EDGE/GPS/WiFi
External adhesive mount solution for automotive and Telematics applications. Covers all cellular, ISM and WiFi working frequencies in the 700-6000 MHz spectrum.

Product Description

  • Part number: 160-00041
  • Dimensions: 176 x 59 x 11.6mm
  • Mounting method: Adhesive
  • Connector: SMA Male
  • Frequency: Varies depending on band. See datasheet.
  • Gain: Varies depending on environment. See datasheet.
  • Input impedance: 50Ω
  • Polarization: Linear
  • Storage temperature: -40oC to 85oC
  • Operating temperature: -40oC to 85oC

Fiberglass omni-directional outdoor antenna
Omni Directional Outdoor Antenna
UV RESISTANT FIBERGLASS OUTDOOR LTE BAND 31/CDMA/ISM 6dBi
Designed for metering, industrial/environmental monitoring, remote asset monitoring and mesh network applications. Robust design for all weather operation. IP65 waterproof.

Product Description

  • Part number: 160-00048
  • Dimensions: 1094mm
  • Mounting method: Wall mount, bracket included
  • Connector: N type Female, U-bolt
  • Frequency: 450-470MHz
  • VSWR: 1.5:1
  • Gain: 6dBi
  • Input power: 100W
  • Input impedance:  50Ω
  • Polarization: Vertical
  • Storage temperature: -40oC to 85oC
  • Operating temperature: -40oC to 85oC

4G multiband wall mount antenna
4G Multiband External Wall Mount Omni Antenna
WATERPROOF COMPACT OMNI ANTENNA
Suitable for 4G/LTE, 3G and GSM bands.

Product Description

  • Part number: 160-00064
  • Dimensions: 159 x 34mm +L-bracket
  • Mounting method: Mounting bracket
  • Connector: N-female
  • Frequency: 690-960/1710-2170/2500-2700MHz
  • VSWR: <2.7:1/<2.5:1/<1.6:1
  • Gain: 2-3dB
  • Input power: 10W
  • Input impedance: 50Ω
  • Polarization: Linear – Vertical
  • Storage temperature: -40oC to 85oC
  • Operating temperature: -40oC to 85oC

CMO 4G Multiband MIMO puck antenna
CMO 4G Multiband MIMO Puck Antenna
LOW PROFILE PUCK ANTENNA
Fully waterproof when mounted. Typically used outside outdoor cabinets.

Product Description

  • Part number: 160-00057
  • Dimensions: 102 x 33.5mm
  • Mounting method: Heavy duty screw mount
  • Connector: SMA Male
  • Frequency: 690-800/800-960/1710-2170/2500-2700MHz
  • VSWR: <2.5:1-3.0:1
  • Gain: 1/2.5/3.8/5dBi
  • Input power: 10W
  • Input impedance: 50Ω
  • Polarization: Linear
  • Storage temperature: -40oC to 85oC
  • Operating temperature: -40oC to 85oC

Stingray glassmount antenna
Stingray Glassmount Antenna
GPS AND PENTA-BAND CELLULAR ADHESIVE
Combination high performance GPS/cellular antenna to simplify AVL or fleet management systems worldwide. It can be attached to glass or under a dashboard.

Product Description

  • Part number: 160-00051
  • Dimensions: 55 x 1.8mm
  • Mounting method: Adhesive
  • Connector: Standard1-10m RG174 cables and connectors
  • Frequency: 10MHz min
  • VSWR: <=2.0
  • Gain: 30dB
  • Input power:
  • Input impedance: 50Ω
  • Polarization: RHCP
  • Storage temperature: -40oC to 85oC
  • Operating temperature: -40oC to 85oC

FGO Penta-band high gain omni antenna
HIGH GAIN OMNI ANTENNA
Supports GSM, 3G and 4G/LTE operation. Ideal for fringe networks.

Product Description

  • Part number: 160-00063
  • Dimensions: 354 x 345mm including bracket
  • Mounting method: Mounting bracket
  • Connector: N-female
  • Frequency: 790-960/1710-2170/2500-2700MHz
  • VSWR: <2.5:1
  • Gain:4/5/4dBi
  • Input impedance: 50Ω
  • Polarization: Linear
  • Temperature range: -40oC to 70oC
